Smart Electronics RF Source Module MAX2870 Board Point and Sweep Frequency 23.5-6000Mhz Source Module for Communications, Radio Infrastructure

Products > Development Board > Smart Electronics RF Source Module MAX2870 Board Point and Sweep Frequency 23.5-6000Mhz Source Module for Communications, Radio Infrastructure

Smart Electronics RF Source Module MAX2870 Board Point and Sweep Frequency 23.5-6000Mhz Source Module for Communications, Radio Infrastructure

RF Source Module MAX2870 Board Point and Sweep Frequency 23.5-6000Mhz Source Module for Communications, Radio Infrastructure

Item Type: RF Source Module
Model: MAX2870
Material: PCB
Frequency Output Range: 23.5-6000Mhz. 2 Modes: Point frequency and sweep frequency
Minimum Control Accuracy: 0.001Mhz
Amplitude Control: -4dB-1dB +2dB +5dB
Power Supply Mode: USB 5V power supply

shared：

RF Source Module, USB 5V Power Supply MAX2870 Board Point and Sweep Frequency 23.5-6000Mhz Source Module for Communications,Radio Infrastructure

Product Description

Feature:
1. [EXCELLENT SYNTHESIZER] The MAX2870 module adopts high performance frequency
synthesizer that can work in integer and fractional N modes.
2. [FREQUENCY RANGE] The frequency range of the RF source module is 23.5-6000Mhz,
with 2 modes of point frequency and sweep frequency.
3. [HIGH PERFORMANCE] This module can maintain good phase noise and spurious indicators,
with stable and less interference.
4. [SIMPLE CONTROL] Powered by USB 5V, support button to adjust frequency output or
serial device (not included) control.
5. [MULTIPLE USAGES] Widely used in radio infrastructure, test and measurement, satellite
communications, clock generators and other fields.

Specification:
Item Type: RF Source Module
Model: MAX2870
Material: PCB
Frequency Output Range: 23.5-6000Mhz. 2 Modes: Point frequency and sweep frequency
Minimum Control Accuracy: 0.001Mhz
Amplitude Control: -4dB-1dB +2dB +5dB
Power Supply Mode: USB 5V power supply
Control Method:
1. Adjust the frequency output through the 5 buttons on the board.
2. Serial Port Control Mode 1: Onboard USB to serial port chip, computer can directly control, no control software is provided.
3. Serial Port Control Mode 2: Through the board serial port interface, it is controlled by other hardware devices.

Package List:
1 x RF Source Module

Note:
Do not overload to use.
