China 12 Years Custom OEM Circuit Board SMT PCB Assembly Service Electronics Manufacturer Offering Custom PCBA Assembly

shared：

PCB Capacities and Technical Specification
Order Quantity	1-500,000
Layer	1, 2, 4, 6, up to 24 layer
Material	FR-4, High Tg, Isola, Aluminum, Rogers, etc
PCB type	Rigid, flexible, rigid-flexible
Shape	Rectangular, round, slots, cutouts, complex, irregular
Max PCB dimensions	1200mm*600mm
Thickness	0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance	± 10%
Copper thickness	0.5-6 oz
Copper thickness tolerance	± 0.25oz
Surface finish	HASL, LF HASL, Imm Gold, Imm Silver, OSP etc
Solder mask	Green, red, white, yellow, blue, black, orange, purple
Silk screen	White, black
Silk screen min line width	0.006'' or 0.15mm
Min drill hole diameter	0.01'', 0.1mm or 10 mil
Min trace/gap	0.075mm or 3mil
PCB cutting	Shear, V-score, tab-routed

PCBA Capacities and Technical Specification
PCBA	PCB+components sourcing+assembly+package
Assembly details	SMT and Thru-hole, ISO SMT and DIP lines
Lead Time	Prototype : 15 work days. Mass order : 20~25 work days
Testing on products	Testing jig/mold , X-ray Inspection, AOI Test, Functional test
Quantity	Min quantity : 1pcs. Prototype, small order, mass order, all OK
Files needed	PCB : Gerber files(CAM, PCB, PCBDOC) Components : Bill of Materials(BOM list) Assembly : Pick-N-Place file
PCB Panel Size	Min size : 0.250.25 inches(66mm) Max size : 1200*600mm
Components details	Passive Down to 0201 size BGA and VFBGA Leadless Chip Carriers/CSP Double-sided SMT Assembly Fine Pitch to 0.8mils BGA Repair and Reball Part Removal and Replacement
Component package	Cut Tape, Tube, Reels, Loose Parts
PCB+ assembly process	Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing
