5mm lightweight Resistor LDR photoresistor 5528 wholesale and retail photoconductive resistance

shared：

Model Number	5528/5MM37
Type	Metal Film Resistor
Spectral Peak(nm)	540
Maximum Voltage (VDC)	150
Resistance	1 MΩ to < 1 GΩ
Temperature Coefficient	-30~+70
Max Consumption(mw)	100
Capacitance	100UF
Bright resistance (10Lux) (K Ω)	30-50

Performance and Characteristics

Epoxy resin encapsulation Good reliability
Small size
High sensitivity
Fast response time
Good spectral characteristics

Application scope

Camera automatic metering
Photoelectric control
Indoor light control
A burglar alarm
Industrial control
Light control switch
Light control lamp
Electronic toy

Packaging and precautions

Avoid storing photoresistor in humid and high temperature environment;
Welding time should be as short as possible;
Note that the welding position of the lead wire should be at least 4mm away from the ceramic base.Maximum applied voltage: The maximum voltage that can be continuously applied to the component in the darkDark resistance: The resistance value at the 10th second after turning off 10Lux of light
Maximum power consumption: The maximum power consumption at an ambient temperature of 25 ℃Bright resistance: Test value of 10Lux using a standard light source (color temperature 2856K) after 2 hours of exposure to 400-600Lux light intensity
