12864 CS1 CS2 5V KS0108 Dot matrix LCD display module

Products > LED/LCD Module > 12864 CS1 CS2 5V KS0108 Dot matrix LCD display module

12864 CS1 CS2 5V KS0108 Dot matrix LCD display module

12864-6, graphic dot formation liquid crystal display module. It is mainly composed of line drives and column drives, can display 128 (column) x 64 (rows) lattice. Can complete graphical display, also can display
8 x 4 (16 * 16 dot matrix Chinese characters.
shared:


12864-6, graphic dot formation liquid crystal display module. It is mainly composed of line drives and
column drives, can display 128 (column) x 64 (rows) lattice. Can complete graphical display, also can display
8 x 4 (16 * 16 dot matrix Chinese characters.



Seven control instruction, and CPU interface using 8-bit data bus parallel input/output.





Built-in RAM is 512 bytes (4096)



Interface definition



12864 CS1 CS2 5V KS0108 Dot matrix LCD display module



If you have more specifications requirements, pls contact us freely
