Your Current Position: Products

Smart Electronics Mini PWM DC motor speed regulator DC-3V 6V 12V 24V 35V speed control switch 5A LED dimmer
Smart Electronics PWM DC motor speed regulator 1.8V 3V 5V 6V 12V 2A speed control switch 1803BK motor control module
Smart PWM DC motor speed regulator 12V24V10A high-power DC controller speed regulation, temperature control, dimming switch

Input voltage range: DC12V-30V
Applicable current range: rated 7A, maximum 10A
Speed range: 5-100%. If it is less than 5%, the motor can be stopped and the potentiometer switch can be turned off
Smart Electronics 3A DC 12-36V speed regulator PWM DC motor speed control module (external potentiometer)

3A DC 12-36V speed regulator PWM

Module parameters
Input voltage: DC12V-36V
Continuous current: 3A, maximum 6A (cooling fan needs to be added when maximum)
Pulse width modulation duty cycle: 0-100%
Pulse width modulation frequency: 500 kHz
Dimensions (L * W * H): 56mm * 36mm * 22mm
Smart Electronics PWM DC motor speed controller switch function board 3V-5V-12V-35V fan motor LED dimming module

5A DC 4.5-35V speed regulator PWM
Module parameters
Working voltage: DC4.5V-35V
Output current: 0-5A
Output power: 90W (maximum)
Static current: 7UA (standby)
PWM duty cycle: 1% -100%
PWM frequency: 20KHz
Size: 30MMX26MMX14MM (excluding handle)
Smart Electronics 60A DC10-50V PWM speed controller PWM DC motor speed regulator module

60A DC 10-50V speed regulator PWM
Module parameters
Working voltage: DC10V-DC50V
Control power: 0.01-3000W
Input current: Maximum 60A (long-term use recommended 30A)
Static current: 0.04A
PWM duty cycle: 5% -100%
PWM frequency: 15KHz
Size: Length 122 * Width 87 * Height 32MM (excluding potentiometer adjustment part)
Smart Electronics PWM DC motor speed regulator DC 9V12V24V36V48V55V brushed motor controller 40A

Product Parameters:
Input voltage: DC9-55V
Output voltage: Linear under load
Output current: 0-40A
Continuous power: 2000W
Speed regulation type: flow regulation
Speed regulation method: potentiometer (linear)
Speed range: 0-100%
Control frequency: 25KHZ
Wiring type: Fence type terminal block
Knob specification: 100K (148)
Module size: Length * Width * Height 83MM * 56MM * 28MM
Motherboard installation dimensions: length * width 72MM * 48MM
Potentiometer installation hole: 7MM
Smart Electronics CCM2 DC motor speed regulator 10V12V24V30V forward and reverse PWM DC controller 120W

Technical parameter

1. Input voltage requirement: 10V-36VDC (wide range)
2. Maximum output power: 150W
3. The maximum continuous current is 5A, the overload short-circuit protection current is 8A, and the short-circuit time does not exceed 30 seconds
4. PWM pulse width modulation range: 0% -100%
5. Size Description
Size: Length and width 73.5mm * 45.5mm
Approximately 27m in height
According to the hole center distance of 63.5mm * 36.5mm
Positioning hole diameter 3.5mm
Smart Electronics 20A PWM DC motor speed regulator DC9-60V frequency 25KHZ potentiometer with switch knob

Input voltage: DC9-60V
Output voltage: Linear under load
Output current: 0-20A
Speed regulation type: flow regulation
Speed range: 5% -100%
Speed regulation method: potentiometer (linear)
Control frequency: 25KHZ
Knob wire length: 20cm
Wiring type: Fence type terminal block
Module size: 75mm * 45mm * 28mm
Customer note: Brushless motors and fans are not suitable for this speed controller
Smart Electronics ESP32-S3 DevKitC-1 Development Board WROOM-1-N16R8 Module ESP32-C3

ESP32-S3 DevKitC-1 Development Board WROOM-1-N16R8 Module ESP32-C3

ESP32-C3 DevKitM-1 Development Board
ESP32-S3-DevKitC-1 development board without soldering pins
ESP32-S3 DevKitC-1 Development Board Welding Pin
ESP32-S3 development board N8R2 without soldering pins
ESP32-S3 Development Board N8R2 Welding Pin
ESP32-S3 development board N16R8 without soldering pins
ESP32-S3 Development Board N16R8 Welding Pin
Smart Electronics 0.49 inch 0.5 inch OLED 64x32 ssd1315 0.49 OLED display screen highlighted OLED

0.49 inch 0.5 inch OLED 64x32 ssd1315 0.49 OLED display screen highlighted OLED
Smart Electronics Single Layer Amplifier PCB Empty Board Printed Plate Power Amplifier PCB Board

Single Layer Amplifier PCB Empty Board Printed Plate Power Amplifier PCB Board
