Smart Electronics Turnkey PCB Manufacturing and Assembly Services for Consumer Electronics PCB

Turnkey PCB Manufacturing and Assembly Services for Consumer Electronics PCB
shared：

PCBA Capacities and Technical Specification
PCBA
PCB+components sourcing+assembly+package
Assembly details
SMT and Thru-hole, ISO SMT and DIP lines
Lead Time
Prototype : 15 work days. Mass order : 20~25 work days
Testing on products
Testing jig/mold , X-ray Inspection, AOI Test, Functional test
Quantity
Min quantity : 1pcs. Prototype, small order, mass order, all OK
Files needed
PCB : Gerber files(CAM, PCB, PCBDOC)
Components : Bill of Materials(BOM list)
Assembly : Pick-N-Place file
PCB Panel Size
Min size : 0.25*0.25 inches(6*6mm)
Max size : 1200*600mm
Components details
Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package
Cut Tape, Tube, Reels, Loose Parts
PCB+ assembly process
Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing


PCB Capacities and Technical Specification
Order Quantity
1-500,000
Layer
1, 2, 4, 6, up to 24 layer
Material
FR-4, High Tg, Isola, Aluminum, Rogers, etc
PCB type
Rigid, flexible, rigid-flexible
Shape
Rectangular, round, slots, cutouts, complex, irregular
Max PCB dimensions
1200mm*600mm
Thickness
0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance
± 10%
Copper thickness
0.5-6 oz
Copper thickness tolerance
± 0.25oz
Surface finish
HASL, LF HASL, Imm Gold, Imm Silver, OSP etc
Solder mask
Green, red, white, yellow, blue, black, orange, purple
Silk screen
White, black
Silk screen min line width
0.006'' or 0.15mm
Min drill hole diameter
0.01'', 0.1mm or 10 mil
Min trace/gap
0.075mm or 3mil
PCB cutting
Shear, V-score, tab-routed


FAQ

Q1.What is needed for quotation?

A1: PCB : Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...)

PCBA: PCB information, BOM, (Testing documents...)

Q2: MOQ?
A2: There is no MOQ in Smart.We are able to handle Small as well as large volume production with flexibility.
Q3: Which type of PCBs do you expert in?

A3: We are specialized in producing Singe-side PCB,Double-side PCB, Multilayer PCB,Aluminium PCB,

Spray Tin PCB,Immersed Gold PCB,etc.

Q4: What is your Lead time?

A4: Lead time is usually punctual here, usually 3-7 days for PCB sample, 7-15 days for mass production.

For some special situation,we can also advise customer in advance to avoid any inexpectation or loss at customer side.

Q5: I only have the pcb sample, not pcb file, can you produce it for me?
A5: Yes, we can copy file based on your sample, this file names gerber, and production then is accorded to gerber file.
Q6: What is your testing policy and how you controle the quality?

A6: For sample, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by fixture,

this will be more faster. Due to there’s many steps to PCB production, we usually do inspection after every step.

Q7: Is Smart a factory or trade company?

A7: Smart is a 12-year experienced professional contract manufacturer to provide one stop Turnkey PCB

assembly and electronics manufacturing service.

Q8: Will my file be safe after you get it ?

A8: Yes , we will not release your design to third party unless with your permission .And we can signthe

NDA before you send the file.

Q9: Do you accept process materials supplied by clients?
A9: Yes, we can provide component source, and we also accept component from client
Q10: How to calculate the shipping cost?

A10: The shipping cost is determined by the destination, weight, packing size of the goods.

Please let us know if you need us to quoteyou the shipping cost.
