PCBA Multilayer Assembly PCB Electronic Board Manufacturer

Here below is our main services for PCB assembly:

Surface Mount Technology
Pin Through-hole Assembly
CE,RoHS,ISO9001:2015
Selective Wave Soldering
Conformal Coating
Complete box build
Inspection Methods

Please provice BOM, so we can check and quote parts and assembly prices. Thanks.

Share

PCBA Capabilities


Turnkey PCBA

PCB+components sourcing+assembly+package

Assembly details

SMT and Thru-hole, ISO SMT and DIP lines

Lead Time

Prototype : 15 work days.  Mass order : 20~25 work days

Testing on products

Testing jig/mold , X-ray Inspection, AOI Test, Functional test

Quantity

Min quantity : 1pcs. Prototype, small order, mass order, all OK

Files needed

PCB : Gerber files(CAM, PCB, PCBDOC)

Components : Bill of Materials(BOM list)

Assembly : Pick-N-Place file

PCB Panel Size

Min size : 0.25*0.25 inches(6*6mm)

Max size : 1200*600mm

Components details

Passive Down to 0201 size

BGA and VFBGA

Leadless Chip Carriers/CSP

Double-sided SMT Assembly

Fine Pitch to 0.8mils

BGA Repair and Reball

Part Removal and Replacement

Component package

Cut Tape, Tube, Reels, Loose Parts

PCB+ assembly process

Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing
