Smart Electronics R2 Upgrade Package PCB Keyboard PCBA Circuit Board PC&FR4 Positioning Board

Products > PCB > Smart Electronics R2 Upgrade Package PCB Keyboard PCBA Circuit Board PC&FR4 Positioning Board

Smart Electronics R2 Upgrade Package PCB Keyboard PCBA Circuit Board PC&FR4 Positioning Board

R2 Upgrade Package PCB Keyboard PCBA Circuit Board PC&FR4 Positioning Board

shared：

PCB Capacities and Technical Specification
MOQ	5 pcs
Layer	1, 2, 4, 6, up to 24 layer
Material	FR-4, High Tg, Isola, Aluminum, Rogers, etc
PCB type	Rigid, flexible, rigid-flexible
Shape	Rectangular, round, slots, cutouts, complex, irregular
Max PCB dimensions	1200mm*600mm
Thickness	0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance	± 10%
Copper thickness	0.5-6 oz
Copper thickness tolerance	± 0.25oz
Surface finish	HASL, LF HASL, Imm Gold, Imm Silver, OSP etc
Solder mask	Green, red, white, yellow, blue, black, orange, purple
Silk screen	White, black
Silk screen min line width	0.006'' or 0.15mm
Min drill hole diameter	0.01'', 0.1mm or 10 mil
Min trace/gap	0.075mm or 3mil
PCB cutting	Shear, V-score, tab-routed

PCBA	PCB+components sourcing+assembly+package
Assembly details	SMT and Thru-hole, ISO SMT and DIP lines
Lead Time	Prototype : 15 work days. Mass order : 20~25 work days
Testing on products	Testing jig/mold , X-ray Inspection, AOI Test, Functional test
Quantity	Min quantity : 1pcs. Prototype, small order, mass order, all OK
Files needed	PCB : Gerber files(CAM, PCB, PCBDOC) Components : Bill of Materials(BOM list) Assembly : Pick-N-Place file
PCB Panel Size	Min size : 0.250.25 inches(66mm) Max size : 1200*600mm
Components details	Passive Down to 0201 size BGA and VFBGA Leadless Chip Carriers/CSP Double-sided SMT Assembly Fine Pitch to 0.8mils BGA Repair and Reball Part Removal and Replacement
Component package	Cut Tape, Tube, Reels, Loose Parts
PCB+ assembly process	Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing

Information required for quotation(Provided by the customers)

PCB : Gerber File / Technological Requirements/Quantity

PCBA: Gerber File / Technological Requirements/BOM List/Quantity

Q1: MOQ? Can I just buy 1 piece?
A1: There is no MOQ in Smart.We are able to handle Small as well as large volume production with flexibility. 1 piecs is OK ,as long as you can accept the sample price
Q2: What is your Lead time?
A2: Lead time is usually punctual here, usually 3-7days for sample, 10-15 days for mass production. For some special situation,we can also advise customer in advance to avoid any inexpectation or loss at customer side.
Q3: What's the best price you can offer?
A3: It depends on the quantity you order. The more quantity ordered, the more favorable the price will be. Both new and existing customers will enjoy corresponding discounts.Anything can be negotiated, so feel free to consult us if you have any questions.
Q4: Besides this product, what other products can you offer?
A4: We offer one-stop service for PCB/PCBA/FPC/Clone boards/stencil/membrane switch and complete components sourcing( Modules, Cable, Sensors, NTC, Aluminum heatsink, Water block,Copper tube,LCD,LED,Switches and Connectors etc.) with a wide range, good quality and reasonable prices according to your need.
Q5: Do you have any relevant certificates for this product?
A5: Yes. Our certificates are complete. If you need them, please contact our salesperson.
