5 megapixel wide angle 65 degree OV5647 camera module suitable for Raspberry Pi

shared：
Pixel
5 million
Photosensitive chip
0V5647
Static image resolution
2592X1944
Support
1080P.30 720P60 and 640X480P60/90 video and recording
Size
25MM * 24MM * 9MM
Instructions for use: Connection method: Connector position: 90 degree vertical connector, next to the HDM port, with the contact side facing towards the HDMI port when connecting 1. The RPI firmware and RASPI-CONFIG have been updated for the camera, please execute an APT-GET UPDATE; APT-GET UPGRADE; 2. RASPI=Select CAMERA in CONFIG, start the camera driver in RPI firmware, and then restart; 3. Use the command line programs RASPIVID and RASPISTILL to operate the camera and capture video clips or images; How to play the data of the camera through live streaming on the network: Use the NC command (NCAT CONNECTE AND REDIRECT SOCKETS) to redirect the input data of the camera directly to the network port for output
