New Arrival Raspberry Pi 3 Model B+ Wide Angle Camera 5MP Adjustable-focus Mini Vision Video Camera module

Products > Raspberry Pi Series > New Arrival Raspberry Pi 3 Model B+ Wide Angle Camera 5MP Adjustable-focus Mini Vision Video Camera module

New Arrival Raspberry Pi 3 Model B+ Wide Angle Camera 5MP Adjustable-focus Mini Vision Video Camera module

Temperature (Operation): -20°C to 70°C
Temperature (Stable Image) : 0°C to 50°C
Focus :Fixed
Object distance:30CM-∞
Resolution: 800LW/PH (Center)
Working power supply : 3.3v(pin15)
Operating system: for Raspberry Pi
Certifications :FCC and CE
Sensor Type: OV5647 (1/4” )
Active Array Size : 2592*1944
Sensitivity: 600mV/Lux-sec
F/No: 2.35
EFL: 1.55 mm
BFL(Optical): 3.1mm
FOV: 160°
TV Distortion :<14.5%
Relative Illumination (Sensor) : 70%
IR Filter : 650±10nm
shared:


Features:
Temperature (Operation): -20°C to 70°C
Temperature (Stable Image) : 0°C to 50°C
Focus :Fixed
Object distance:30CM-∞
Resolution: 800LW/PH (Center)
Working power supply : 3.3v(pin15)
Operating system: for Raspberry Pi
Certifications :FCC and CE
Sensor Type: OV5647 (1/4” )
Active Array Size : 2592*1944
Sensitivity: 600mV/Lux-sec
F/No: 2.35
EFL: 1.55 mm
BFL(Optical): 3.1mm
FOV: 160°
TV Distortion :<14.5%
Relative Illumination (Sensor) : 70%
IR Filter : 650±10nm
