Smart Electronics 433MHz 315MHz RF Wireless Transmitter and Receiver Module DIY Remote Control Module with Antenna

433MHz 315MHz RF Wireless Transmitter and Receiver Module DIY Remote Control Module with Antenna
shared：

Smart Electronics 433MHz 315MHz RF Wireless Transmitter and Receiver Module DIY Remote Control Module with Antenna
Operating Voltage
DC 3~5V
Quiescent Current
1μA
Maximum Current
5mA
RF Frequency
433.92MHz
Bandwidth
±150KHz
Transmission Rate
2KHz to 10KHz
Operating Temperature
-30°C to +80°C
Receiver Sensitivity
-110dBm
RF Mode
ASK/OOK Superheterodyne Wireless Reception

Wide Availability :

Remote switches, receiver modules, motorcycles, automotive anti-theft products,

home security products, electric gates, rolling doors, windows, remote-controlled outlets,

remote-controlled LEDs, remote-controlled audio systems, remote-controlled electric gates, garage

door remotes, retractable remote-controlled gates, remote-controlled volume gates, sliding gates,

remote door openers, door closer control systems, remote-controlled curtains, alarm control panels,

alarms, remote-controlled motorcycles, remote-controlled electric devices, remote-controlled MP3 players.
