Smart Electronics DIY HIFI M18 Stereo Wireless 4.2 MP3 Audio Receiver board Module Decoder Board MH-M18

DIY HIFI M18 Stereo Wireless 4.2 MP3 Audio Receiver board Module Decoder Board MH-M18

This product MH-M18 is a low-power Bluetooth design solution that supports the latest Bluetooth 4.2 transmission, supports Bluetooth automatic reconnection technology, and supports dual channel stereo lossless playback. After the module is connected to Bluetooth, it can quickly achieve Bluetooth wireless transmission, which is very convenient. In an open environment, the Bluetooth connection distance can reach up to 20 meters. Widely used in various Bluetooth audio reception, various audio DIY modifications, etc.
shared：


Product Description
This product MH-M18 is a low-power Bluetooth design solution that supports the latest Bluetooth 4.2 transmission, supports Bluetooth automatic reconnection technology, and supports dual channel stereo lossless playback. After the module is connected to Bluetooth, it can quickly achieve Bluetooth wireless transmission, which is very convenient. In an open environment, the Bluetooth connection distance can reach up to 20 meters. Widely used in various Bluetooth audio reception, various audio DIY modifications, etc.
Welcome to your kindly inquiry : )
KEY: Key control terminal (4 key functions, additional resistors need to be added during operation) MUTE: Mute control terminal (output high-level 33V during mute, output low-level during playback) VCC: Power supply positive pole 5V (lithium battery 3.7V power supply hand bean circuit two poles) GND: Negative pole of power supply L: Left channel output R: Right channel output
